PELCO LatticeAx 420晶圆切割机

PELCO® LatticeAx® 420 Sample Cleaving System, 220V

大客户经理
销售经理

咨询热线：0755-23003036

产品详情

The PELCO^® LatticeAx^® 420 (formerly from LatticeGear™) provides the highest level of accuracy and performance in the PELCO^® LatticeAx^® Indent and Cleaving System model lineup. The PELCO^® LatticeAx^® 420 delivers our highest cleaving accuracy of 10μm in less than 5 minutes making it ideal for any lab that values speed and high accuracy while at the same time needing to accommodate a variety of sample sizes, thicknesses and material types. The patented PELCO^® LatticeAx^® base is integrated with a complete vision package that includes a monocular microscope with 4μm optical resolution, color CCD camera and real-time image acquisition and display software, and an X-Y stage. This dedicated cleaving workstation is designed so any trained user can easily survey, align, micro-indent, cleave, and inspect processed samples.

Features

Ultra high accuracy positioning of target (±10µm)
Focus mount with coarse and fine focus control
Monocular, parfocal, zoom lens (0.58-7x mag) with color CCD camera
(computer and monitor not included)
Indent position control with 5µm step size
Polished tip diamond indenter 5 minute process sample setup to cleave
Simple to use, ergonomic design and small footprint
Cleaves a wide range of materials and sample sizes
Clock dial for indent depth calibration

Prod #	Description	Unit
54300	PELCO^® LatticeAx^® 420 Sample Cleaving System, 110V	each
54300-220	PELCO^® LatticeAx^® 420 Sample Cleaving System, 220V	each
