with pliers from the EUROline series

Set for working on electronic components without mobile person grounding

with dissipative tools 10^6 to 10^9 ohm

complies with standard DIN EN 61340-5-1

2 empty compartments for individual placements

conductive synthetic case 10^2 to 10^5 ohm

precise conductive foam

opening angle 180°

measures 350 x 310 x 65 mm

weight 1250 g

EPA suitable for electrostatically protected areas (ESD workplace / ESD protection zone). Professional tool set for the repair and maintenance of complex electronic components and assemblies.

Selected ESD tools in a handy plastic case made of dissipative material. The tools are clearly arranged in dimensional recesses made of dissipative rigid foam. There are also 1 or 2 empty compartments for individual requirements.

ESD tool kit TRENDY consists of:

2281 ESD conductive synthetic case with foam insert empty;

2-620 PLCC-extractor;

3-133-13 ESD side cutters 145 mm dissipative;

3-651-15 ESD mini side cutters EUROline flush 120 mm;

3-682-15 ESD flat nose pliers EUROline not serrated jaws 130 mm;

3-683-15 ESD snipe nose pliers EUROline not serrated jaws 130 mm;

4-603 ESD screwdriver slot blade 1.5x0.25x60 mm;

4-605 ESD screwdriver slot blade 2.0x0.4x60 mm;

4-606 ESD screwdriver slot blade 2.5x0.4x60 mm;

4-621 ESD screwdriver cross-recess PH000;

4-622 ESD screwdriver cross-recess PH00;

4-623 ESD screwdriver cross-recess PH0;

5-049-13 ESD SMD tweezers 110 mm form 4 stainless steel dissipative;

5-055-13 ESD SMD tweezers 120 mm form 7a stainless steel angle 40° dissipative;

5-059-13 ESD SMD tweezers 120 mm form 2a stainless steel dissipative;

6-661 ESD torx screwdriver T5;6-662 ESD torx screwdriver T6;

6-663-L ESD torx screwdriver T7 with hole;

7-422 ESD brush bristles width 20 mm
