PELCO^® Conductive Gold Paste

resistant to oxidation and retains measurement integrity over time

Gold paste is fast drying and useful for analytical analysis over time where a high signal is desired. The gold is in microfine form and contains organic binders and a solvent. Dries at room temperature. Not intended for permanent use, but for testing and temporary work. Sheet resistance is .02 to .05 ohm/sq @ 1 mil thickness. Contacts hold down to very low temperatures (<-200°C), but are not permanent since this type of product has low mechanical strength. 75% gold content; sphere size <2µm, flake size <10µm. Maximum service temperature is 65°C.
Refrigerate for best life. Bring to room temperature gradually. Approximate calculated specific gravity 3.18g/cm³.
